Description
HEAVY-DUTY SUSPENSION TRAINER MOUNT
Multi-Point Metal Hardware
for Training Systems.
The Heavy-Duty Suspension Trainer Mount features a four-hole mounting plate combined with a multi-point welded anchor structure for suspension, resistance and bodyweight-training equipment.
This model demonstrates one possible way to create multiple equipment attachment directions from a fixed steel mounting plate.
Connection geometry, plate design, mounting-hole arrangement and fastener configuration can be modified or completely redesigned according to the intended training system.
PRODUCT TYPE
Multi-Point Suspension Mount
MATERIAL
Steel
MOUNTING
Four-Hole Plate
ANCHOR STRUCTURE
Multi-Point Welded Geometry
CUSTOMIZATION
Plate · Anchor · Holes · Connection · Fasteners
DEVELOPMENT
OEM · ODM · Custom Metal Fabrication
CONNECTION GEOMETRY
The Connection Point
Can Be Part of the Design.
The welded structure shown here creates multiple attachment directions, but the final connection geometry does not need to follow this exact arrangement.
Depending on the training equipment, the hardware can be developed with different loop positions, connection directions, plate geometry and mounting layouts.
CUSTOM METAL HARDWARE
Don’t Limit the Product
to Existing Hardware.
Our existing suspension mounts are manufacturing references — not a fixed catalog that limits what your product can become.
If your design requires a different mounting shape, attachment direction, hole pattern or fastening method, ZJSD can help evaluate and manufacture a new metal structure around the original concept.
DON’T DESIGN THE PRODUCT AROUND AN OFF-THE-SHELF ANCHOR.
DEVELOP THE ANCHOR AROUND THE PRODUCT.
HARDWARE DEVELOPMENT OPTIONS
From Small Modifications
to New Structures.
PLATE DESIGN
Modify dimensions, shape and structural direction.
HOLE LAYOUT
Develop mounting-point quantity and positioning.
WELDED GEOMETRY
Develop new attachment structures and orientations.
CONNECTION POINTS
Configure single or multiple equipment interfaces.
FASTENERS
Match fastening configuration to the installation requirement.
FINISH
Coordinate coating, color and appearance with the equipment.
FROM STANDARD TO CUSTOM
Choose How Far
You Want to Develop It.
EXISTING MODEL
Start from a current mounting structure.
MODIFICATION
Change size, holes, finish or fasteners.
CUSTOM STRUCTURE
Develop new plate and connection geometry.
SYSTEM DEVELOPMENT
Develop mounting hardware around the complete training product.
OEM / ODM PROCESS
From Designer’s Intent
to Metal Hardware.
→ CONNECTION LOGIC
→ INSTALLATION CONDITION
→ METAL STRUCTURE
→ SAMPLE
→ PRODUCTION
The purpose of development is to translate the designer’s intended function into manufacturable hardware while preserving the original product direction as effectively as possible.
DESIGNING A NEW TRAINING SYSTEM?
Don’t Search for Hardware
That Almost Fits.
Show us how your equipment is intended to connect and install. Start with a drawing, sample, reference photo or simply the product concept.
ZJSD can help develop and manufacture mounting hardware around the original design intent.
DEVELOP YOUR MOUNTING SYSTEM →
CUSTOM METAL HARDWARE · SUSPENSION TRAINING · OEM · ODM · PRODUCT DEVELOPMENT
