SUSPENSION TRAINER WOOD MOUNT
A Mounting Solution
Designed Around Wood Structures.
The Suspension Trainer Wood Mount is a welded steel mounting fixture shown with a two-hole mounting plate and fasteners configured for suitable structural timber applications.
It provides a fixed connection point for suspension trainers, gym rings, resistance systems and other bodyweight or functional-training equipment.
This configuration is only one reference design. ZJSD can modify or redesign the mounting plate, hole layout, anchor geometry, connection structure, fastener configuration and surface finish around your equipment and installation concept.
PRODUCT TYPE
Suspension Training Mount
ANCHOR MATERIAL
Steel
MOUNTING STRUCTURE
Two-Hole Mounting Plate
FASTENER DIRECTION
Wood / Timber Installation
CUSTOMIZATION
Geometry · Holes · Connection · Finish · Fasteners
DEVELOPMENT
OEM · ODM · Custom Metal Fabrication
WOOD MOUNTING CONFIGURATION
The Fastener Is Part
of the Mounting System.
The fastener configuration shown with this model is intended as a wood-mounting direction. For a custom project, the mounting structure and supplied fasteners should be considered together according to the intended installation substrate.
INSTALLATION SURFACE → FASTENER CONFIGURATION → MOUNTING PLATE → CONNECTION STRUCTURE
CUSTOM MOUNTING HARDWARE DEVELOPMENT
This Design Is a Reference.
Not Your Only Option.
Your suspension product does not need to be designed around the mounting hardware we already manufacture.
If your original concept requires a different plate, attachment point, mounting geometry or fastening method, ZJSD can work from your drawing, sample, reference product or design concept to help develop a suitable metal mounting solution.
THE GOAL IS NOT TO MAKE YOUR DESIGN FIT OUR HARDWARE.
THE GOAL IS TO DEVELOP HARDWARE THAT FITS YOUR DESIGN.
CUSTOM METAL FABRICATION
Redesign the Hardware
Around the Training System.
PLATE GEOMETRY
Develop different plate shapes, dimensions and structures.
HOLE LAYOUT
Configure mounting-hole quantity, position and arrangement.
ANCHOR GEOMETRY
Develop loops, eyes and welded attachment structures.
CONNECTION POINTS
Configure the equipment interface around the training concept.
FASTENER SYSTEM
Match the fastening direction to the intended installation substrate.
SURFACE FINISH
Coordinate coating, color and appearance with the finished equipment.
OEM / ODM DEVELOPMENT
From Design Intent
to Manufactured Hardware.
→
INSTALLATION REQUIREMENT
→
HARDWARE CONCEPT
→
STRUCTURE DEVELOPMENT
→
SAMPLE
→
PRODUCTION
DON’T DESIGN THE PRODUCT AROUND AN OFF-THE-SHELF ANCHOR — DEVELOP THE ANCHOR AROUND THE PRODUCT.
START YOUR PROJECT
Start from a Drawing,
Sample or Product Idea.
NEED A DIFFERENT MOUNT?
Show Us How Your Product
Is Intended to Work.
Send us your drawing, sample, reference photo or product concept. ZJSD can help develop custom mounting hardware around your equipment and intended installation.
